1 x 1.7MW Condensing with Extraction Steam Turbine-Generator Package (NEW) 50hz

1 x 1.7MW Condensing with Extraction Steam Turbine-Generator Package (NEW) 50hz

Contact us for price

Location:Robertsbridge, United Kingdom

Description

1 x 1.7MW Condensing with Extraction Steam Turbine-Generator Package

Condition: NEW

Year of Manufacture: 2018

Hours of Operation: 0, as new, never installed.


Turbine:

Make: Howden (KKK)

Type: Condensing with Extraction (Twin)


First Stage:

Rated Output: 1,730KW (Max)

Inlet Mass Flow: 8.01t/hr (Max)

Inlet Steam Temperature: 480 Deg C

Inlet Steam Pressure: 90 Bar

Exhaust Pressure: 7.5 Bar


Second Stage:

Rated Output: 1,730KW (Max)

Inlet Mass Flow: 6.5t/hr (Max)

Inlet Steam Temperature: 244 Deg C

Inlet Steam Pressure: 7.3 Bar

Exhaust Pressure: 0.1 BarInlet Steam Temperature: 415Deg C

Inlet Steam Pressure: 43 Bar

Exhaust Pressure: 0.135 Bar

Speed: 6,500 RPM


Gear

Manufacturer: KKK

Output Speed: 1,500 RPM


Alternator

Manufacturer: Leroy Somer

Rated Output: 2,000 KVA

Power Factor: 0.8

Voltage: 400kV

Frequency: 50Hz

Speed: 1,500 RPM


Condenser

Type: Water Cooled


UEN 3744

Specifications

ManufacturerHowden
Year2018
ConditionUsed
Stock NumberUEN 3744
