1 x 40t/hr Heat Recover Steam Generator (HRSG) & 12MW Steam Turbine-Generator Package (USED) 50Hz

1 x 40t/hr Heat Recover Steam Generator (HRSG) & 12MW Steam Turbine-Generator Package (USED) 50Hz

Contact us for price

Location:Robertsbridge, United Kingdom

Description

1 x 40t/hr Heat Recover Steam Generators (HRSG) & 12MW Condensing with Extraction Steam Turbine-Generator Package

This is a 'bolt on' steam cycle opportunity for an existing gas turbine package.


Condition: Used

Hours of Operation: ~50,000


HRSG:

Manufacturer: IST (INNOVATIVE STEAM TECHNOLOGIES)

Type: OTSG (ONCE THROUGH)

Year of Manufacture: 2011

HP Steam Pressure: 66 barg

HP Steam Temperature: 470 °C

HP Mass Flow: 39t/hr

LP Steam Pressure: 7.8 barg

LP Steam Temperature: 215 C

LP Mass flow: 8.5t/hr


ST:

12MW Condensing with Extraction Steam Turbine-Generator Package

Condition: Used

Hour of Operation: ~50,000

Make: GE Oil & Gas

Inlet Temperature: 470 Deg C

Inlet Pressure: 62 Bar

Extraction Pressure: 20.5 Bar & 6 Bar


Alternator Voltage/Frequency: 11.5kv / 50Hz

Condenser: Water Cooled


Original Application: Behind 1 x LM2500 Gas Turbine-Generator.

UEN 3757

Specifications

ManufacturerGE
Year2010
ConditionUsed
Stock NumberUEN 3757
